SEGRO Park Berlin Airport

PHASE 7

• Warehouse height: Light Industrial: 6.5 m clear height Urban Logistics: 8.5 m clear height
• Floor load: 5 t/sq m (Forklift trucks with a maximum total load of 5 t)
• Each unit is equipped with 2 – 3 doors:
  • Ground-level gates:
    • Building V-Y: 3m W x 4.5m H
    • Building U: 5m W x 4.60m H
  • Additional loading ramps with loading door (3m W x 3.3m H) and electro-hydraulic dock leveller
• Windows in the warehouse area
• LED lighting
• Skylights for optimum lighting conditions and ventilation
• Energy-saving construction, DGNB Platinum certification targeted
• Separate supply to each unit with district heating, water, green electricity for optimisation of ancillary costs
• 63 A power backup for each unit; can be increased if necessary

PHASE 1-4

• Warehouse height: 6 m clear height
• Floor load: 5 t/sq m (forklifts with a maximum permitted load of 5 t/sq m)
• Each unit is equipped with 2 doors:
  • Sectional door (3 m W x 4.2 m H), for ground-level access
  • Additional loading ramps with loading door (3 m x 3 m) and electro-hydraulic dock leveller
• Windows in the warehouse area
• LED lighting
• Skylights for optimum lighting conditions and ventilation
• Energy-saving construction, DGNB certified
• Separate supply to each unit with district heating, water and electricity for optimisation of ancillary costs
• 63 A power backup for each unit; can be increased if necessary

PHASE 3

• Warehouse height: 10.5 m clear height
• Windows: Aluminum windows with insulated glazing
• Warehouse floor:
  - Storage area: Floor evenness according to DIN 18202, Table 3, Line 4
  - Picking area: Floor evenness according to DIN 18202, Table 3, Line 3
• Floor load capacity: 50 kN/sqm
• Lighting: LED equipment
  - Illuminance in the storage area: 200 lux
  - Illuminance in the picking area: 250 lux
• Heating: up to 17°C in the warehouse (radiant tube heaters)
• Fire protection: ESFR sprinkler system
• Offices and social areas: high-quality equipped
• Car parking spaces: 16

FUTURE DEVELOPMENT

• Warehouse height: 12 m clear height
• Warehouse floor:
  • Steel fiber concrete slab
  • Load capacity of 50 kN/sq m (5t) and point loads from shelf columns of 75 kN
• Doors:
  • Sectional door (4 m W x 4.5 m H) for ground-level delivery
  • 18 electro-hydraulic dock levelers (Unit 1: 8 levelers, Unit 2: 10 levelers)
• Windows: Aluminum windows with insulated glazing
• Lighting: Intelligent LED lighting systems
• Utilities:
  • Electricity and water connection per rental unit
  • Electrical protection per rental unit 63 A
  • Warehouse heating via VRF systems
  • Office heating via heat pump system
• Sprinkler system FM Global
• Office: 1 mezzanine office per rental unit (including sanitary facilities and driver registration)

LIGHT INDUSTRIAL

• Green roofs on office buildings
• PV system with 1 MWp
• E-charging stations for electric cars
• Charging options for bicycles
• BEG40 standard
• Designated species protection areas
• Rainwater storage tank for park irrigation
• Aiming for DGNB Platinum certification

LOGISTICS

• Green electricity supply through photovoltaic system
• Charging stations for electric vehicles (20% of all car parking spaces)
• Sustainable greening concept with green roofs
• High-quality insulated building envelope (BEG 40)
• Aiming for DGNB Platinum and DGNB Climate Positive certification
